Programátor EZP2019+ s 12 FLASH EEPROM adaptérmi

Programátor EZP2019+ v súprave s 12 adaptérmi umožňujúcimi pohodlné programovanie širokej škály systémov aj tých, ktoré sa pridávajú ručne v súboroch .cap

Vďaka prídavným adaptérom bude sada fungovať nielen v domácnosti ale aj pre profesionálne použitie, zlepšujúce pohodlie a rýchlosť práce. Vďaka adaptérom a verzii "plus" tento model podporuje väčšie množstvo systémov vrátane tých napájaných 1,8V Má rozhranie USB 2.0, vysokú rýchlosť zápisu a čítania až 12Mbps - napríklad pamäť EN25T80 s a. kapacitu 8 Mbit možno prečítať za 3 sekundy a uložiť za 9 sekúnd. Dá sa použiť napríklad na opravu domácich spotrebičov, hodí sa na blikanie televízorov, DVD prehrávačov, základných dosiek počítačov a čipov veľkokapacitných pamäťových zariadení na pevných diskoch a iné.

Programátor:

• rozpozná typ zasunutej pamäte
• rozpozná, či je čip správne umiestnený v zásuvke
• automaticky zvolí napájacie napätie
• má príp. funkcia kopírovania pamäť
• podporuje 25 FLASH, 24 EEPROM, 25 EEPROM, 93 EEPROM

Vrátane adaptérov:

• TSSOP8
• SOP8 150mil
• SOP8 209mil
• SOP16-DIP8 300mil
• Adaptér SOP8 s klip
• MSOP8
• 2 x QFN8/WSON8
• 2 x SO8/SO16
• adaptér pre 1,8V systémy
• Kábel LED/LCD 2v1

Špecifikácia:

• Napájanie USB
• Rýchlosť programovania: 12 Mbps
• podporuje Čipy EEPROM, Flash I2C a SPI
• zásuvka na zasunutie čipov: ZIP16
• možnosť použitia ďalších adaptérov
• funguje so systémami: Windows XP, Windows Vista , Win7, WIN8, WIN10
• USB kábel súčasťou balenia
• kompaktné rozmery: 65 mm x 45 mm x 18 mm

Podporované pamäte:

*** 25 SPI FLASH ***

AMIC: A25L05P, A25L512 , A25L010, A25L10P, A25L020, A25L20P, A25L040, A25L40P, A25L080, A25L80P, A25L016, A25L16P, A25L032

Atmel : AT25F512, AT25F512A, AT25F512B, AT25F1024, AT25F1024A, AT25FS010, AT25F021, AT25F ATI>: EN25F05, EN25LF05, EN25P05, EN25D10, EN25F10, EN25F20, EN25F20, EN25F20, EN25Q80, EN25T80, EN25B16, EN25B16T, EN25D16, EN25F16, EN25F16 EN25Q16, EN25T16, EN25B32, EN25B32T, EN25F32, EN25P32, EN25Q32, EN25B64, EN25B64T, EN25F64, EN25P64, EN25Q64, EN25F128, ES25P ES25P20, ES25M40, ES25M40A, ES25P40, ES25M80, ES25M80A, ES25P80, ES25M16, ES25M16A, ES25P16, ES25P32

ESMT, F25L04: F25L0A F25L008A, F25L08PA, F25L016A, F25L16PA, F25L32PA, F25L32QA

MXIC: MX25L512, MX25V512, MX25L1005, MX525L2 MX25V4005, MX25L8005, MX25V8005, MX25L1605D, MX25L1635D, MX25L3205D, MX25L3225D, MX25L3235D, MX25L3237L6D, MX25L3237L6D, MX25L3237L6D MX25L12805D

NexFlash: NX25P10, NX25P20, NX25P40, NX25P80, NX25P16, NX25P32

PMC: PM25LV512LV2PM2A, PM25LV5120PM, PM PM25LV040, PM25LV080B, PM25LV016B

SAIFUN: SA25F005, SA25F010, SA25F020, SA25F040, SA25F080, SA25F160, SA25F320, SA25F320:SPAN: S25FL004A, S25FL008A, S25FL016A, S25FL032A, S25FL064A

SST: SST25VF512, SST25VF512A, SST25VF010, SST25VF010A, SST25VF00A, SST25VF000 SST25VF040, SST25VF040A, SST25VF040B, SST25VF080B, SST25VF016B, SST25VF032B, SST25VF064C

ST: M25P050A, M501 M20 M25PE20, M25P40, M25PE40, M25P80, M25PE80, M25PX80, M25P16, M25PE16, M25PX16, M25P32, M25PX32, M25P64, M25PX64, M25P128

WINBOND: W25P10, W25X10, W25X10A, W25X10AL, W25X10L, W25P20, W25X20, W25X25, W40, W40X25A, W24X20AL, W25X20 W25X80L, W25P16, W25X16, W25P32, W25X32, W25X64

*** 24 EEPROM ***

ATMEL:AT24C01, AT24C01A, AT24C01B, AT AT24C02A, AT24C02B, AT24C04, AT24C04A, AT24C04B, AT24C08, AT24C08A, AT24C08B, AT24C24, ATC64, AT24C6464, AT24C16B, AT24C24, CAT64, AT24C 6A, AT24C256B, AT24C512, AT24C512A, AT24C512B, AT24C1024, AT24C1024A, AT24C1024B

KATALYZÁTOR:CAT24C01,2C01C424W0 CAT24C04, CAT24WC04, CAT24C08, CAT24WC08, CAT24C16, CAT24WC16, CAT24C32, CAT24WC32, CAT24C64, CAT24WC64, CAT24C24, CAT4C24 CAT, CAT24 CAT24C128, CAT24C

BEŽNÉ: 24C00 3V, 24C00 5V, 24C01 3V, 24C01 5V, 24C02 3V, 24C02 5V, 24C04,8243V, 24C04,823V, 24C08 5V, 24C16 3V, 24C16 5V, 24C32 3V, 24C32 5V, 24C64 3V, 24C64 5, 24C128 3V, 24C128 5V, 5V, 24C25, 24C25 24C512 3V, 24C512 5V, 24C1024 3V, 24C1024 5V

FAIRCHILD: FM24C01L, FM24C02L, FM24C03L, FM24C04L, FMC4 FM04 FM29L, FM29M FM24C16L, FM24C17L, FM24C32L, FM24C64L, FM24C128L, FM24C512L, FM24C512L, FM24C256L,

HOLTEK:HT24C01, HT24LC201, HT24LC01, HT24LC01, HT24C04, HT24LC04, HT24C08, HT24LC08, HT24C16, HT24LC16, HT24C32, HT24LC32, HT24C64, HT24LC64, HT24C128 HT24C128 HT24C25,HT24C25,HT24C25,HT24C256, HT24

ISSI: IS24C01, IS24C02, IS24C04, IS24C08, IS24C16, IS24C32, IS24C64, IS24C128, IS24C256, IS24C512, IS24C1024

MIKROCHIP: 24AA00, 24C00, 24LC00, 24AA01, 24AA014, 24C01C, 24,24001BAA, 24,24001BAA 24LC02B, 24AA024, 24AA025, 24AA04, 24C02C, 24LC024, 24LC025, 24LC04B, 24AA08, 24LC08B, 24LC16, 24LC16B, 24LC26B64LC,24LC 24AA128, 24FC128, 24LC128, 24AA256, 24FC256, 24LC256, 24AA512, 24FC512, 24LC512, 24AA1024

NSC, NSC4C02, NSC206L RAMTRON: FM24C04A, FM24CL04, FM24C16A, FM24CL16, FM24C64, FM24CL64, FM24C256, FM24CL256, FM24C512

ROHM: BR24C01,CBR01, BR424L, BR24C04, BR24L04, BR24C08, BR24L08, BR24C16, BR24L16, BR24C32, BR24L32, BR24C64, BR24L64

ST, ST24C04C8, ST24C04C8, ST24C04C 16, ST24C32, ST24C64 XICOR: X24C01, X24C02, X24C04, X24C08, , AK93C75AV

ATC: ATC93C46, ATC93LC46 (16bit), ATC93LC46 (16bit) -SOP8, ATC93LC46 (8bit), ATC93LC46 (8bit) -SOP8, ATC93C56,56 (16bit), 56 ATC93 ATC93LC56 (16bit) -SOP8, ATC93LC56 (8bit), ATC93 ) -SOP8, ATC93C66, ATC93LC66 (16bit), ATC93LC66 (16bit) -SOP8, ATC93LC66 (8bit), ATC93LC66 (8bit) - SOP8

ATMELATC /b>: AT93C46 (16bit), ATI AT93C57 (16bit) -SOP8, AT93C57 (8bit), AT93C57 (8bit) -SOP8, AT93C66 (16bit), AT93C66 (16bit) -SOP8, AT93C66 (8bit), AT93C66 (8bit) -SOP8, AT16bit) -SOP8, AT16bit )) - SOP8, ATI , CAT93C56A, CAT93C57 (16bit), CAT93C57 (16bit) -SOP8, CAT93Cbit (9366) (1666) CAT93C66A, CAT93C86 (16bit), CAT93C86 (8bit)

BEŽNÉ (163C)4 , 93C46 (8bit), 93C56 (16bit), 93C56 (8bit), 93C66 (16bit), 93C66 (8bit), 93C86 (16bit), 93C86 (8bit)

EXEL: XL93C06, XL93C46, XL93CS46 , XL93LC46, XL93C56, XL93LC56, XL93C66, FM93C46AN (8bit), FM93C16 (16bit), FM93CS1616 (16bit), FM93CS56 (16bit), FM93C66AM8 (16bit), FM93C66AM8 (8bit), FM93C66AN (16bit), FM93C66AN (86bit), FMC86, FM96, FM93 FM93C66MT8 (16bit), FM93C16AM (93bit), FM93C16N (16bit) 16bit), FM93C86AM8 (8bit), FM93C86AN (16bit), FM93C86AN (8bit)

HOLTEK: AHT93LC ) ), HT93LC46A (8bit), HT93LC56A (16bit), HT93LC56A (8bit), HT93LC66A (16bit), HT93LC66A (8bit)

ICT: ICT93C46 (16bit), ICT93C46 (8bit), ICT93C56 (16bit), ICT93C56 (8bit), ICT93C66 (16bit), ICT93C66 (8bit) ISSI: IS93C46 (16bit), IS93C56 (16bit), IS93C66 (16bit)

MIKROCHIP: 93C06 (16bit), 93C06 (16bit) - SOP8, 93AA46 (16bit), 93AA46 (8bit), 93AA46 (8bit) - SOP8, 93C46 (16bit), 93C46 (16bit) -SOP8, 93C46A, 93C46B, 93LC46 (16bit), 93LC46 (16bit) -SOP8, 93LC46, 843bit), 468A (843bit), 468A 93LC46B, 93LC46B-SOP8, 93AA56 (16bit), 93AA56 (8bit), 93AA56 (8bit) -SOP8, 93C56 (16bit), 93C56 (16bit) -SOP8, 93C56 (83C96), 56SOP -86A 93C56A-SOP8, 93C56B, 93C56B-SOP8, 93LC56 (16bit), 93LC56 (16bit) -SOP8, 93LC56 (8bit), 93LC56 (8bit) -SOP8, 93LC556A,8B6LC 93AA66 (16bit), 93AA66 (8bit), 93AA66 (8bit) -SOP8, 93C66 (16bit), 93C66 (16bit) -SOP8, 93C66 (8bit), 93C66 (8bit) -SOP8, 93C66A,93C66A,93C66A,8B 93C66B-SOP8, 93LC66 (16bit), 93LC66 (16bit) -SOP8, 93LC66 (8bit), 93LC66 (8bit) -SOP8, 93LC66A, 93LC66B, 93LC66B-SOP8 (816bit), 937AA76, 933AA76 93C76 (16bit), 93C76 (8bit), 93LC76 (16bit), 93LC76 (8bit), 93LC76A, 93LC76B, 93AA86 (16bit),93AA86 (8bit), 93C86 (16bit), 93C866 (8bit), 93C866 (8bit), 93C866 (8bit), 93LC76B, 93LC76B, 93AA86 (16bit), (8bit), 93LC86A, 93LC86B

NSC: NSC93C06, NSC93C06-SOP8, NSC93CS06, NSC93C46, NSC93CS46, NSC93C56, NSC93CS56, NSC663,5SC6, NSC663S NSC93C86

ROHM: BR93LC46, BR93LC46RF, BR93LC56, BR93LC56RF, BR93LC66, BR93LC66RF

ST: ST93C06, M93S46, M SOP8, M93S46-T8, M93S46R, M93S46R-SOP8, M93S46W, M93S46W-SOP8, ST93C46, M93S56, M93S56-SOP8, M93S56R, M93S56R-SOP8, M93S56C, M93SOP8, M93SOP8, M93SOP8 M93S66R, M93S66R-SOP8, M93S66W, M93S66W-SOP8, ST93C66

*** 25 EEPROM ***

ATMEL: AT25010, AT25020, AT25040 AT25080, AT25160, AT25320, AT25640, AT25128, AT25256, AT25512

KATALYZÁTOR: CAT25C01, CAT25C01P, CAT25C01S, CAT25C01U, CAT25C02P, CAT2C05C02P, CAT2CCAT25C02 CAT25C03S, CAT25C03U, CAT25C04P, CAT25C04S, CAT25C04U, CAT25C05P, CAT25C05S, CAT25C05U, CAT25C08P, CAT25C08S, CAT2905C08, CAT2905C08 CAT25C09U, CAT25C16P, CAT25C16S, CAT25C16U, CAT25C17P, CAT25C17S, CAT25C17U, CAT25C32P, CAT25C32S, CAT25C33P, CAT25C33P, CAT2C25C33 CAT25C65P, CAT25C65S, CAT25C128P, CAT25C128S, CAT25C128S

BEŽNÉ: 25010, 25020, 25040, 25080, 25150, 260, 28 25256, 25512

MIKROCHIP: 25AA040, 25C040, 25LC040, 25AA080, 25C080, 25LC080, 25AA160, 25C160, 25LC160, 25AA320, 25C320, 25LC320, 25AA640, 25C640, 25C640:p>LC64RAM FM25C160, FM25640, FM25CL64

ST: ST25C01, ST25W01, ST25C02, ST25W02, ST25C04, ST25W04, ST25C08, ST25W08, ST25W16, ST25C16, ST25W16, ST TI: TI2532, TI2532A, TI2564

XICOR: XC25010, XC25020, XC25040, XC25080, XC25160, XC25320, XC25640, XC25252C8,55X251p>2C8,55X251p
